Item Description

1 BEZEL

2 PANEL

3 BKT-PANEL-TOP

4 BKT-PB

5 BRACKET

6 BRACKET

7 BRACKET

Item Part No. Description Qty

8 REAR COVER 27 0Q1G 930 8 47 CR3 SCREW(BKT/BEZEL) 2

9 BKT-STAND 28 001G6021 1 SCREW(SPEAKER/BEZEL) 4

10 FIX_BKT_M 29 0Q1G1030 6120 SCREW(BEZEL/IR BOARD) 1

11 BASE 30 0Q1G 940 16 47 CR3 SCREW(PANEL/BEZEL/REAR COVER/BEZEL) 14

12 BKT-BASE-A2 31 0M1G1830 8120 SCREW(BKT/POWER BOARD) 5

13 STAND_ASSY 32 0M1G1740 10120 SCREW(PANEL/BKT) 5

14 FIX_BKT_S 33 0M1G 940 6120 SCREW(PANEL/BKT) 12

15 KEY BUTTON 34 0M1G 130 6120 SCREW(PANEL/BKT) 1

16 KEY COVER 35 0M1G1730 6120 SCREW(PANEL/BKT/MAIN BOARD) 5

17 LED LENS 36 0Q1G 930 8 47 CR3 SCREW(BKT/MAIN BOARD/REAR COVER) 2

18 IE LENS_A2 37 0M1G 930 6 47 CR3 SCREW(BKT/MAIN BOARD) 2

19 DECO_BEZEL_TV 38 0M1G 940 8 47 CR3 SCREW(REAR COVER/BKT) 4

20 BKT-VESA-BTM 39 0Q1G 940 30 47 CR3 SCREW(BEZEL/REAR COVER) 4

21 RUBBER 40 0M1G 940 10 47 CR3 SCREW(PANEL/HINGE) 2

23 FOOT PAD 41 0Q1G 130 8 47 CR3 SCREW(BESE/BKT) 6

25 BKT-FIX-PANEL 42 Q01G6145 1 SCREW(BESE/BKT) 4
