AOC LE40A1330/64 User Manual

56
10. BOM List
Note: The following information of initial version BOM are only for reference of repair, not place the order as the
basis and are subject to change without notice. Please base on RSPL or Service BOM (http://cs.tpv.com.cn) , thank
you!
E39D2KNCCQACNNX
Location Part No. Description Remark
P34T11890GMZ3K02BA REAR_COVER
X41G40MV61502B MANUAL LE40A1330/64 Philippines
036T 600 18111 NONWOVEN FABRTC
052G 1186 SMALL TAPE
052G 2191 A PAPER TAPE
ECN701 095G801313DS05 HARNESS 13P-13P 400
ECN701 095G801313WS05 HARNESS 13P-13P 400mm 2nd source
0M1G1030 6 47 CR3 SCREW
0M1G1730 6120 SCREW 3x6
0M1G1730 8120 SCREW 3x8
0M1G1740 8120 SCREW FOR STD/MF 42-D020715/42-D000649()
0M1G1740 10225 CR3 SCREW M1-MACHINE SCREW x10.0
0Q1G 130 6120 SCREW (T3X6)
0Q1G 930 8 47 CR3 SCREW
0Q1G 940 8 47 CR3 SCREW 4x8
0Q1G 940 12 47 CR3 SCREW 4x12
0Q1G1030 6120 SCREW 3x6
SP01 378G0110567YAH 16 OHM 11W 132X34 0 NO
ECN601 395G801404DY11 HARNESS 4P-B&R+B&W 450/260mm 2nd source
ECN601 395G801404XY11 HARNESS 4P-B&R+B&W 450/260
ECN4004 395G801410WY38 HARNESS 10P-5P+4P 650/750 2nd source
ECN4004 395G801410XY38 HARNESS 10P-5P+4P 650/750
ECN4001 395G801851DY98 LVDS CABLE 51P-30P 400mm
ECN4001 395G801851RY98 LVDS CABLE 51P-30P 400 2nd source
708GTA070CPX03 AOC 40 (504 Philippines)
Q45G 77 5 PE PACKING
Q50G 4 10 TIE (Y1900221)
Q52G 1185 99 BIG CARTON TAPE FOR AOC 72MM
756TXCCB0KC0280002 MAIN BAORD-CBPFCK8DX6
SMTF-U4003 100TARVT009C2X MCU ASSY-356G2233073
040G 45762412B OTHER LABEL
CN4004 033G380210B YH L CONNECTOR 10P 2.0
C616 067G315M1016KV EC 100UF 20% 35V 8*7
C601 067G315M1016KV EC 100UF 20% 35V 8*7
CN107 088G 302A11 YG PHONE JACK 3.5¦µ 7PIN BLACK CKX3.507B-01
CN102 088G 78G114ACL RCA JACK R/A YELLOW H=10.5
CN103 088G 78G121ACL RCA JACK R/A 4P W/R 1*2 H=10.5
CN103 088G 78G121AQS RCA R/A 4P 1*2 - 10.5mm
CN101 088G 78G134ACL RCA JACK R/A 6P G/BL/R 1*3 H=10.5
CN106 088G302G3G2ACL PHONE JACK R/A 3P GREEN H=10mm
CN106 088G302G3G2AQS PHONE JACK R/A 3P GREEN H=10
CN107 088G302G7B1ACL PHONE JACK R/A 7P BLACK H=10.5
CN107 088G302G7B1AQS PHONE JACK R/A 7P BLACK H=10.5mm
CN108 088G352F6B2ACL USB CONN R/A 6P BLACK 8.4mm
CN105 088G353GFF1AXH D-SUB CONN 15P BLUE - R/A 10
TU101 094G PALALL10L TUNER China DT21WN-2-E
CN601 311GW200A04ABX WAFER 2.0mm 4P

AOC LE40A1330/64 Specifications

General

Brand	AOC
Model	LE40A1330/64
Category	LCD TV
Language	English
