AOC U32P2CA User Manual

3
Installation
Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a
person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by
the manufacturer or sold with this product. Follow the manufacturer’s instructions when installing the product and use
mounting accessories recommended by the manufacturer. A product and cart combination should be moved with care.
Never push any object into the slot on the monitor cabinet. It could damage circuit parts causing a re or electric
shock. Never spill liquids on the monitor.
Do not place the front of the product on the oor.
If you mount the monitor on a wall or shelf, use a mounting kit approved by the manufacturer and follow the kit
instructions.
Leave some space around the monitor as shown below. Otherwise, air-circulation may be inadequate hence
overheating may cause a re or damage to the monitor.
To avoid potential damage, for example the panel peeling from the bezel, ensure that the monitor does not tilt
downward by more than -5 degrees. If the -5 degree downward tilt angle maximum is exceeded, the monitor damage will
not be covered under warranty.
See below the recommended ventilation areas around the monitor when the monitor is installed on the wall or on the
stand:
Installed with stand
Installed with stand
12 inches
30cm
4 inches
10cm
4 inches
10cm
4 inches
10cm
Leave at lease this
space around the set

AOC U32P2CA Specifications

General

Panel type	VA
Color depth	8 bit
Pixel pitch	0.18159 x 0.18159 mm
Aspect ratio	4:3, 16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	Matt
Display diagonal	31.5 \
Surface hardness	3H
Anti-glare screen	Yes
Adobe RGB coverage	88 %
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	40 - 60 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 140 kHz
Supported video modes	1080p, 1440p, 2160p
Viewable size, vertical	392.234 mm
sRGB coverage (typical)	119 %
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	80 cm
Viewable size, horizontal	697.306 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080), 2560 x 1440, 3840 x 2160
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB Power Delivery up to	65 W
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Tilt angle range	-5 - 21.5 °
Height adjustment	150 mm
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SER
Certification	ISO
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	110 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	57 W
RMS rated power	3 W
Compatibility	VESA-P2
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Cables included	AC, DisplayPort
DisplayPort cable length	1.8 m
Package type	Box
Package depth	224 mm
Package width	810 mm
Package height	538 mm
Package weight	12800 g
Exterior finish type	Textured
Harmonized System (HS) code	85285210
Sustainability certificates	WEEE

Weight and Dimensions

Depth (with stand)	275.1 mm
Height (with stand)	- mm
Weight (with stand)	10100 g
Depth (without stand)	55.7 mm
Width (without stand)	714.8 mm
Height (without stand)	425.2 mm
Weight (without stand)	9800 g
