APRILIA eSR2 User Manual

09
6. Assembly and conguration
The vehicle is delivered folded and with the handlebar removed.
NOTICE
Steps:
1. Open the kickstand
2. Unfold the handlebar tube and secure it with the locking hook
3. Install the handlebar on the rod (beware not to atten the wires)
4. Insert the screws inside into the hole located under the control panel
5. Tighten the screws with the hexagonal key provided
6. Try to turn the e-scooter ON/OFF.
7. Charge the battery to 100%
8. Adjust the folding mechanism**
9. Adjust the braking system (chapter 9)
10. Check the tyre pressure (36 PSI)*
*If the scooter has not travelled at least 60% of the stated km or reached the maximum
speed in the rst 3 months of use, it is likely that the wheels have deated again, it will thus
be necessary to restore the pressure as indicated (36 PSI).
** If the handlebar rod is loose, you can tighten the screw on the folding system lever.

APRILIA eSR2 Specifications

General

Type	Classic scooter
Foldable	Yes
Motor type	Brushless
Wheels type	Solid wheels
Maximum speed	25 km/h
Product color	Black, Red
Frame material	Aluminum
Motor position	Rear wheel
Wheel material	Rubber
Maximum gradient	15 °
Number of wheels	2 wheel(s)
Rear brake system	Drum brake
Display technology	LED
Front brake system	Electric
Recommended gender	Any gender
Maximum load weight	100 kg
Displayed parameters	Battery status, Distance traveled, Speed
Recommended age (min)	14 yr(s)
Suitable for surface type	Asphalt
Front tire size (imperial)	10 \
Distance per battery charge (max)	25 km
Motor power	350 W
Charging time	5 h
Battery voltage	36 V
Battery capacity	8 Ah
Package type	Box
Seat included	No

Weight and Dimensions

Depth	450 mm
Width	1215 mm
Height	1185 mm
Weight	16500 g
Folded height	550 mm
Package depth	170 mm
Package width	1230 mm
Package height	600 mm
Package weight	18500 g
