Correct disposal of this product (Waste Electrical & Electronic Equipment)

This symbol means the product must not be discarded as household waste, and should be delivered to an appropriate collection facility

for recycling. Proper disposal and recycling helps protect natural resources, human health and the environment. For more information on

disposal and recycling of this product, contact your local municipality, disposal service, or the shop where you bought this product.

This product is RoHS compliant.

This product is in compliance with Directive 2011/65/EU, and its amendments, on the restriction of the use of certain hazardous substances

in electrical and electronic equipment.

REACH

REACH (Regulation No 1907/2006) addresses the production and use of chemical substances and their potential impacts on human health

and the environment. Article 33(1) of REACH Regulation requires suppliers to inform the recipients if an article contains more than 0.1 %

(per weight per article) of any substance(s) on the Substances of Very High Concern (SVHC) Candidate List (‘REACH candidate list’). This

product contains the substance “lead”(CAS-No. 7439-92-1) in a concentration of more than 0.1% per weight.

At the time of release of this product, except for the lead substance, no other substances of REACH candidate list are contained in

aconcentration of more than 0.1% per weight in this product.

Note: On June 27, 2018, lead was added to the REACH candidate list. The inclusion of lead in the REACH candidate list does not mean that

lead-containing materials pose an immediate risk or results in a restriction of permissibility of its use.

Instructions for Users on Removal, Recycling and Disposal of Used Batteries

To remove the batteries from your equipment or remote control, reverse the procedure described in the owner’s manual for inserting

batteries. For products with a built-in battery that lasts for the lifetime of the product, removal may not be possible for the user. In this case,

recycling or recovery centers handle the dismantling of the product and the removal of the battery. If, for any reason, it becomes necessary

to replace such a battery, this procedure must be performed by authorized service centers. In the European Union and other locations, it is

illegal to dispose of any battery with household trash. All batteries must be disposed of in an environmentally sound manner. Contact your

local waste-management ofﬁcials for information regarding the environmentally sound collection, recycling and disposal of used batteries.

WARNING: Danger of explosion if battery is incorrectly replaced. To reduce risk of ﬁre, explosion or leakage of ﬂammable liquid/gas, don’t

disassemble, crush, puncture, short external contacts, expose to temperature above 60°C (140°F), sunshine or like, expose to extremely low

air pressure or dispose of in ﬁre or water. Replace only with speciﬁed batteries. The symbol indicating ‘separate collection’ for all batteries

and accumulators shall be the crossed-out wheeled bin shown below:

According to EU Batteries Directive 2013/56/EU, any batteries, accumulators and button cells containing more than 0.0005 % mercury,

more than 0.002 % cadmium or more than 0.004 % lead, shall be marked with the chemical symbol for the metal concerned: Hg, Cd or Pb

respectively. Please Refer to the below symbol:

PbCdHg

HARMAN International hereby declares that this equipment is in compliance with the essential requirements and other relevant provisions

of Directive 2014/53/EU.

registered in the United States and/or other countries.

Features, speciﬁcations and appearance are subject to change without notice.

Android Google, Google Play, Chromecast, Chromecast built-in, Google Home and other related marks and logos are trademarks of

Google Inc.

Apple, AirPlay and iTunes are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple

Inc.

MQA (Master Quality Authenticated).

MQA is an award-winning British technology that delivers the sound of the original master recording. The master MQA ﬁle is fully

authenticated and is small enough to stream or download.

Visit mqa.co.uk for more information.

Your Arcam AVR includes MQA technology, which enables you to play back MQA audio ﬁles and streams, delivering the sound of the

original master recording.

Need help?

Do you have a question about the Arcam AVR5 and is the answer not in the manual?

Arcam AVR5 Specifications

General

Type	AV Receiver
Amplification	Class AB
Frequency Response	20Hz - 20kHz
HDMI Inputs	7
HDMI Outputs	2
HDMI 2.1	Yes
eARC	Yes
HDMI Version	2.1
HDCP Version	2.3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
Room Correction	Dirac Live
Streaming	Yes
Wi-Fi	Yes
Bluetooth	Yes
Ethernet	Yes
USB	Yes
Input Impedance	47k Ohms
Total Harmonic Distortion	0.2%
Signal-to-Noise Ratio	100dB
DAC	ESS 9026PRO
Dimensions (W x H x D)	433 x 171 x 425 mm
Amplifier Power Output	90W per channel (8 ohms, 20Hz - 20kHz, 0.2% THD)
Input Sensitivity	200mV
USB Port	Type-A (for audio playback)
