Ariel JGJ/4 User Manual

FOR MODELS: JGW, JGR AND JGJ SECTION 4 - LUBRICATION AND VENTING
PAGE 4 - 8 1/01
TABLE 4-1: CYLINDER/PACKING LUBE OIL RECOMMENDATIONS FOR VARIOUS GAS STREAM COMPONENTS
GAS STREAM
CYLINDER DISCHARGE PRESSURE
< 1000 psig
< (70 bar
g
)
1000 to 2000
psig
(70 to 140 bar
g
)
2000 to 3500
psig
(140 to 240 bar
g
)
a
3500 to 5000
psig
(240 to 345 bar
g
)
a
> 5000 psig
> (345 bar
g
)
a
Pipeline Quality
Natural Gas
Including CNG
(Dry)
SAE 40 wt.
ISO 150
Base Rate
or Various
Synthetics
Base Rate
SAE 40-50 wt.
ISO 150 - 220
1.25 x Base Rate
or Various
Synthetics
Base Rate
SAE 50 wt.
ISO 220
w/ Compounding
1.5 x Base Rate
or Various
Synthetics
1.25 x Base Rate
Cylinder Oil
ISO 320 - 460
w/ Compounding
2 x Base Rate
or Synthetic -
Diester/Polyglycol
1.5 x Base Rate
Cylinder Oil
ISO 460 - 680
w/ Compounding
3 x Base Rate
or Synthetic -
Polyglycol
2 x Base Rate
Natural Gas
(Water Satu-
rated and/or
Heavy
hydrocarbons
b
Methane < 90%
Propane > 8%
SG > 0.7)
SAE 40 - 50 wt.
ISO 150 - 220
1.25 x Base Rate
or Various
Synthetics
Base Rate
SAE 50 - 60 wt.
ISO 220 - 320
or SAE 40 wt.
ISO 150
w/ Compounding
1.5 x Base Rate
or Var. Synthetics
1.25 x Base Rate
Cylinder Oil
ISO 460 - 680
w/ Compounding
2 x Base Rate
or Various
Synthetics
1.5 x Base Rate
Cylinder Oil
ISO 680
w/ Compounding
3 x Base Rate
or Synthetic -
Diester/Polyglycol
2 x Base Rate
Contact Lubricant
Supplier
Natural Gas
(Water Satu-
rated and Carbon
Dioxide
> 2% to 10%)
SAE 40 - 50 wt.
ISO 150 - 220
1.25 x Base Rate
or Various
Synthetics
Base Rate
SAE 50 - 60 wt.
ISO 220 - 320
or SAE 40 wt.
ISO 150
w/ Compounding
1.5 x Base Rate
or Var. Synthetics
1.25 x Base Rate
Cylinder Oil
ISO 460-680
w/ Compounding
2 x Base Rate
or Synthetic PAG
1.5 x Base Rate
Cylinder Oil
ISO 680
w/ Compounding
3 x Base Rate
or Synthetic PAG
2 x Base Rate
Contact Lubricant
Supplier
Natural Gas
(Water Satu-
rated and Carbon
Dioxide
$ 10%)
SAE 40 - 50 wt.
ISO 150 - 220
1.50 x Base Rate
or Various
Synthetics
1.25 Base Rate
SAE 50 - 60 wt.
ISO 220 - 320
or SAE 40 weight
ISO 150
w/ Compounding
2 x Base Rate
or Var. Synthetics
1.5 x Base Rate
Cylinder Oil
ISO 460-680
w/ Compounding
3 x Base Rate
or Synthetic PAG
2 x Base Rate
Cylinder Oil
ISO 680
w/ Compounding
4 x Base Rate
or Synthetic PAG
3 x Base Rate
Contact Lubricant
Supplier
Natural Gas
(Water Satu-
rated and H
2
S
> 2% to 30%)
SAE 40 wt.
ISO 150
w/ Compounding
1.25 x Base Rate
or Various
Synthetics
Base Rate
SAE 40 - 50 wt.
ISO 150 - 220
w/ Compounding
1.5 x Base Rate
or Various
Synthetics
1.25 x Base Rate
SAE 50 wt.
ISO 220
w/ Compounding
2 x Base Rate
or Various
Synthetics
1.5 x Base Rate
SAE 60 wt.
ISO 320
w/ Compounding
3 x Base Rate
or Various
Synthetics
2 x Base Rate
Cylinder Oil
ISO 460 - 680
w/ Compounding
4 x Base Rate
or Various
Synthetics
3 x Base Rate
