Ariens 915243 User Manual

EN - 9
1. Fuel Tank and Cap
2. Fuel Level Window
3. Oil Filter
4. Oil Drain
5. Engine Oil Dipstick
6. Air Filter
7. Ignition Key
8. Choke Control Knob (Models 215243,
915245, 915254)
9. Throttle / Choke Control Lever (Models
915251, 915253)
10. Throttle Control Lever (Models 215243,
915245, 915254)
11. Power Take-off (PTO) Knob
12. Hour Meter
13. Height-of-Cut Adjustment System
14. Deck Lift Pedal
15. Parking Brake Lever
16. Belt Cover (2)
17. Steering Lever (2)
18. Discharge Chute
19. Transaxle Bypass Lever (2)
20. Battery (Under Seat)
CONTROLS AND FEATURES
Figure 3
14
3
4
1
13
17
5
16
5
4
2
15
18
3
6
3
19
11
7
9
8
12
6
5
6
5
4
20
Models 915251, 915253
Models 215243, 915245
Model 915254
10
