Page #30 background imageLoading...
Page #30 background image
English
24
2.4 Expansion Slots (PCI Express Slots)
ere are 4 PCI Express slots on the motherboard.
PCIe slots:
PCIE1 (PCIe 4.0 x16 slot) is used for PCI Express x16 lane width graphics cards.
PCIE2 (PCIe 3.0 x1 slot) is used for PCI Express x1 lane width cards.
PCIE3 (PCIe 3.0 x16 slot) is used for PCI Express x4 lane width graphics cards.
PCIE4 (PCIe 3.0 x1 slot) is used for PCI Express x1 lane width cards.
Before installing an expansion card, please make sure that the power supply is
switched o or the power cord is unplugged. Please read the documentation of the
expansion card and make necessary hardware settings for the card before you start
the installation.
PCIE1 PCIE3
Ryzen Series CPUs (Matisse) Gen4x16 Gen3x4
Ryzen Series APUs (Renoir) Gen3x16 Gen3x4
For a better thermal environment, please connect a chassis fan to the motherboard’s
chassis fan connector (CHA_FAN1/WP, CHA_FAN2/WP, CHA_FAN3/WP or
CHA_FAN4/WP) when using multiple graphics cards.

Other manuals for ASROCK B550 PHANTOM GAMING 4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK B550 PHANTOM GAMING 4 and is the answer not in the manual?

ASROCK B550 PHANTOM GAMING 4 Specifications

General IconGeneral
Processor socketSocket AM4
Processor manufacturerAMD
Compatible processor seriesAMD Ryzen 3 3rd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors1
ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory typesDDR4-SDRAM
Maximum internal memory128 GB
Supported memory clock speeds2133, 2400, 2667, 2933, 3200, 3466, 3600, 3733, 3800, 3866, 4000, 4133, 4200, 4266, 4333, 4400, 4466, 4533 MHz
RAID levels0, 1, 10
Supported storage drive interfacesM.2, SATA III
Parallel processing technology support-
USB 2.0 connectors2
USB 3.2 Gen 2 (3.1 Gen 2) connectors0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity6
Wi-FiNo
LAN controllerRealtek RTL8111H
Ethernet interface typeGigabit Ethernet
Component forPC
Motherboard chipsetAMD B550
Audio output channels7.1 channels
Motherboard form factorATX
BIOS typeUEFI
Harmonized System (HS) code84733020
Weight465 g
Weight and Dimensions IconWeight and Dimensions
Depth244 mm
Width305 mm
Height70 mm
