Asus 4G-AX56 User Manual

32
2. From the Enable Time Scheduling pane, click ON.
3. From the Client Name (MAC Address) column, select or key
in the client’s name from the drop down list box.
NOTE: You may also key in the client’s MAC address in the Client Name
(MAC Address) column. Ensure that the client name does not contain
special characters or spaces as these may cause the router to function
abnormally.
4. Click to add the client’s profile.
5. Click Apply to save the settings.

Asus 4G-AX56 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, WAN
Housing material	Plastic
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	1201 Mbit/s
WLAN data transfer rate (first band)	54 Mbit/s
WLAN data transfer rate (second band)	11 Mbit/s
Antennas quantity	4
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g
Ethernet LAN interface type	Gigabit Ethernet
Flash memory	128 MB
Internal memory	512 MB
Power source type	DC
4G standard	LTE-FDD
3G standards	UMTS
SIM card type	NanoSIM
Mobile network generation	4G
Ethernet LAN (RJ-45) ports	5
Cables included	LAN (RJ-45)
NAT functionality	PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough, PPPoE relay
Security algorithms	IPSec, SIPS

Weight and Dimensions

Weight	753 g
