Asus A8N-SLI - Motherboard - ATX User Manual

ASUS A8N-SLIASUS A8N-SLI
ASUS A8N-SLIASUS A8N-SLI
ASUS A8N-SLI
3-73-7
3-73-7
3-7
4. Insert the second graphics card into the black slot labeled
PCIEX16_2PCIEX16_2
PCIEX16_2PCIEX16_2
PCIEX16_2. Make sure that the card is properly seated on the slot.
If required, connect an auxiliary power source to the PCI Express
graphics cards.
3. Insert one graphics card into the blue slot labeled
PCIEX16_1PCIEX16_1
PCIEX16_1PCIEX16_1
PCIEX16_1. Make
sure that the card is properly seated on the slot.

Asus A8N-SLI - Motherboard - ATX Specifications

General

Form Factor	ATX
Chipset	NVIDIA nForce4 SLI
Socket	Socket 939
Memory Type	DDR
Memory Slots	4 x DIMM
Max Memory	4 GB
LAN	Gigabit LAN
PS/2 Ports	2
Serial Ports	1
Parallel Port	1
Supported CPUs	AMD Athlon 64, AMD Athlon 64 FX, AMD Athlon 64 X2
Expansion Slots	2 x PCIe x16, 2 x PCIe x1, 3 x PCI
Storage Interfaces	2 x PATA
Audio	Realtek ALC850 8-channel
RAID Support	RAID 0, 1, 0+1
USB Ports	10 (4 on back panel, 6 via headers)
