Asus DSL-AC51 User Manual

52
Declaration of Conformity for Ecodesign directive 2009/125/EC
Testing for eco-design requirements according to (EC) No 1275/2008
and (EU) No 801/2013 has been conducted. When the device is in
Networked Standby Mode, its I/O and network interface are in sleep
mode and may not work properly. To wake up the device, press the
Wi-Fi on/o, LED on/o, reset, or WPS button.
This equipment complies with EU radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed
and operated with minimum distance 20 cm between the radiator &
your body.
All operational modes:
2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 5GHz:
802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac
(VHT40)
The frequency, mode and the maximum transmitted power in EU are
listed below:
2412-2472MHz (802.11n HT40 15 Mbps): 19.60 dBm
5180-5240MHz (802.11a 6 Mbps): 22.84 dBm
The device is restricted to indoor use only when operating in the 5150
to 5350 MHz frequency range.
AT BE BG CZ DK EE FR
DE IS IE IT EL ES CY
LV LI LT LU HU MT NL
NO PL PT RO SI SK TR
FI SE CH UK HR
GNU General Public License
Licensing information
This product includes copyrighted third-party software licensed
U13200-1_DSL-AC51_168x125mm_QSG.indb 52 2017/8/18 16:01:38

Asus DSL-AC51 Specifications

General

Certification	CE
Firmware upgradeable	Yes
SIM card slot	No
Firewall security	Parental control
Security algorithms	64-bit WEP, 128-bit WEP, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	433 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Product type	Tabletop router
Product color	Black
LED indicators	ADSL, DSL, LAN, Power, WLAN
Housing material	Acrylonitrile butadiene styrene (ABS)
VPN support	IPSec Pass-Through PPTP Pass-Through L2TP Pass-Through PPTP server OpenVPN server PPTP client L2TP client OpenVPN client
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC, DC
AC input frequency	50 - 60 Hz
Supported network protocols	IPv4, IPv6
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	20 - 90 %
Operating relative humidity (H-H)	50 - 90 %
Antennas quantity	3
Cables included	DSL, LAN (RJ-45), Phone (RJ-11)
Package type	Box
Mac operating systems supported	Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64

Weight and Dimensions

Depth	175 mm
Width	207 mm
Height	200 mm
Weight	440 g
