4 Using the utilities
• Install the wireless router's utilities from the bundled support
CD.
• If Autorun is disabled, run
setup.exe from the root directory
of the support CD.
When you set the router to Access Point mode, you need to use
Device Discovery to get the router’s IP address.
Device Discovery
Device Discovery is an ASUS WLAN utility that detects any ASUS
wireless routers available on the wireless network and allows you
to configure the device.
To launch the Device Discovery utility:
Click Start > All Programs > ASUS Utility > DSL-AC68U Wireless
Router > Device Discovery.

Asus DSL-AC68U Specifications

General

VPN support	IPSec, PPTP, L2TP, PPTP server, OpenVPN server, PPTP client, L2TP client
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
USB version	3.2 Gen 1 (3.1 Gen 1)
Rack mounting	-
Frequency range	2.4 - 5 GHz
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	1
WLAN data transfer rates supported	600, 1300 Mbit/s
Ethernet LAN (RJ-45) ports	4
Antennas quantity	3
Antenna gain level (max)	3 dBi
Security algorithms	256-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
Product color	Black
Flash memory	128 MB
Internal memory	256 MB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	83.3 mm
Width	220 mm
Height	160 mm
Weight	640 g
