6
Setting up
1. Insert your xDSL modem router’s power
adapter to the DC-IN port and plug it to a
power outlet.
2. Connect one end of the RJ-11 cable to
the DSL port of your xDSL modem router,
and connect the other end to the DSL
port of your splitter.
3. Using a network cable, connect your
computer to your xDSL modem router’s
LAN port.
Powering up
1. Turn on your xDSL modem router and wait for a few minutes for Internet connection.
2. When DSL LED stops ashing and lights constantly, you can start the DSL setup process via the
QIS Wizard (Quick Internet Setup Wizard).
NOTE: For more details on QIS, refer to the user manual.
Getting started
1. Launch your web browser, and key in the default user name (admin) and password (admin).
Wall telephone outlet
Computer
Wall Power Outlet
Power
LAN
Splitter
Phone
DSL
To Next Page
