11
Connecting your devices
Wired connection
To set up your ADSL/VDSL router using a wired connection:
1. Insert the splitter’s line connector to the phone outlet and
connect your phone into the phone port.
2. Using the bundled phone cable, connect your DSL-N66U’s
ADSL/VDSL port to the splitter’s DSL port.
3. Using the bundled network cable, connect your computer to
the ADSL/VDSL router’s LAN port.
E
thernet
WAN
DSL
W
AN
Network cable
Wall power outlet
Wall telephone
outlet
• Use a wired connection when setting up your wireless router
to avoid possible wireless setup issues.
• Before setting up your ASUS wireless router, do the following:
• If you are replacing an existing router, disconnect it from
your network.
• Disconnect the cables/wires from your existing modem. If
your modem has a backup battery, remove it as well.
• Reboot your computer (recommended).
