Asus Eee PC 1015B User Manual

Chapter 4: System Recovery 4-2
System Recovery
Disable Boot Booster in BIOS setup before you perform system
recovery from USB flash disk, external optical drive or hidden
partition.
Ensure to connect your Eee PC to the AC power adapter before
using F9 recovery to avoid recovery failure.
Using recovery partition (F9 Recovery)
1. Press <F9> during bootup.
Ensure to press <F9> only once during bootup.
2. Select the language you use and
click
to continue
.
3. Click Recovery in the Recovery
System dialog box to start the
system recovery.
4. The system starts system recovery automatically and follow the
onscreen instructions to complete the recovery process.

Asus Eee PC 1015B Specifications

General

Processor cache	0.512 MB
Processor model	C-30
Processor family	AMD Single-Core
Processor frequency	1.2 GHz
Processor cache type	L2
Processor manufacturer	AMD
GPS (satellite)	No
Motherboard chipset	-
Memory slots	1x SO-DIMM
Internal memory	1 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	2 GB
Memory layout (slots x size)	1 x 1 GB
HDD size	2.5 \
HDD capacity	250 GB
HDD interface	SATA
Card reader integrated	Yes
Compatible memory cards	MMC, SD, SDHC
Display diagonal	10.1 \
Display resolution	1024 x 600 pixels
Native aspect ratio	5:3
Graphics card	Radeon HD 6250
Wireless technology	WLAN 802.11 b/g/n
Front camera resolution (numeric)	0.3 MP
Networking features	Fast Ethernet, WLAN
Ethernet LAN data rates	10, 100 Mbit/s
Audio system	HDA
Number of built-in speakers	2
Operating system installed	Windows 7 Starter
Product type	Netbook
Product color	White
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Pointing device	Touchpad
Battery capacity	5200 mAh
Battery life (max)	8.5 h
Number of battery cells	6
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V

Weight and Dimensions

Depth	178 mm
Width	262 mm
Weight	1300 g
Height (rear)	36.4 mm
Height (front)	23.6 mm
