ASUS EX-B150M-V3
1-1
Product introduction
1
Motherboard overview
• Unplugthepowercordfromthewallsocketbeforetouchinganycomponent.
• Beforehandlingcomponents,useagroundedwriststraportouchasafelygrounded
objectorametalobject,suchasthepowersupplycase,toavoiddamagingthemdue
tostaticelectricity.
• Beforeyouinstallorremoveanycomponent,ensurethattheATXpowersupplyis
switchedofforthepowercordisdetachedfromthepowersupply.Failuretodoso
maycauseseveredamagetothemotherboard,peripherals,orcomponents.
• Unplugthepowercordbeforeinstallingorremovingthemotherboard.Failuretodoso
cancauseyouphysicalinjuryanddamagetomotherboardcomponents.
Place this
side towards
the rear of the
chassis
ScantheQRcodetogetthedetailedpindenitions.
EX-B150M-V3
SATA_PWRCON
PCIEX16
PCIEX1_1
PCIEX1_2
SPEAKER
F_PANEL
CLRTC
TPM
SPDIF_OUT
USB1112
USB3_12
AAFP
COM
EATX12V
EATXPWR
CPU_FAN
CHA_FAN1
BATTERY
Super
I/O
ALC
887
Realtek
8111GR
DIGI
+VRM
LGA1151
Intel
®
B150
DDR4 DIMM_A1 (64bit, 288-pin module) DDR4 DIMM_B1 (64bit, 288-pin module)
SATA6G_1
SATA6G_4 SATA6G_3 SATA6G_2
128Mb
BIOS
22.6cm(8.9in)
18.5cm(7.3in)
AUDIO
LAN_USB78
USB3_56
USB3_34
USB910
KBMS
DVI
21 413
2
5 89
7
6
5
101113
14
15
12
16
17

Asus EX-B150M-V3 Specifications

General

Brand	Asus
Model	EX-B150M-V3
Category	Motherboard
Language	English
