Asus H81M-CS User Manual

vi
(continued on the next page)
H81M-CS specications summary
CPU
LGA1150 socket for the 4th Generation and New 4th Generation Intel
®
Core
TM
i7/ i5 / i3, Pentium
®
and Celeron
®
Processors
Supports 22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
*
Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H81 Express Chipset
Memory 2xDIMMs,max.16GBDDR31600/1333/1066MHz,non-ECC,unbuffered
memory modules
Dual-channel memory architecture
Supports Intel
®
ExtremeMemoryProle(XMP)
* Hyper DIMM support is subject to the physical characteristics of individual
CPUs. Please refer to Memory QVL for details.
** Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
*** Due to Intel
®
chipset limitations, DDR3 1600MHz and higher memory modules
on XMP mode will run at the maximum transfer rate of DDR3 1600MHz.
Graphics
Integrated Graphics Processor - Intel
®
HD Graphics support
Support D-Sub port
- SupportsD-Subwithmax.resolution1920x1200@60Hz
- Maximum shared memory of 1024MB
Expansion slots
1 x PCI Express x16 slot
1 x PCI Express x1 slot
Storage
Intel
®
H81 Express Chipset:
- 2 x Serial ATA 6.0 Gb/s connectors (yellow)
- 2 x Serial ATA 3.0 Gb/s connectors (dark brown)
- Supports Intel
®
Rapid Start Technology* and Intel
®
Smart Connect
Technology**
* Due to the limitation of the Intel
®
H81 chipset, Intel
®
Rapid Start Technology can
be congured only from the BIOS Setup program.
** These functions will work depending on the CPU installed.
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS H81M-CS motherboard
Cables 2 x Serial ATA 6.0 Gb/s cables
Accessories 1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.

Asus H81M-CS Specifications

General

Form Factor	Micro ATX
Chipset	Intel H81
CPU Socket	LGA 1150
Memory Slots	2
Maximum Memory	16 GB
Memory Type	DDR3
PCIe x16 Slots	1
PCIe x1 Slots	2
USB 3.0 Ports	2
USB 2.0 Ports	8
Audio	Realtek ALC887
LAN	Realtek 8111G
Video Outputs	DVI, VGA
