Notebook PC User Manual
31
IMPORTANT! Only use battery packs and power adapters
supplied with this Notebook PC or specifically approved by the
manufacturer or retailer for use with this model or else damage
may occur to the Notebook PC.
1
2
3
To remove the battery pack:
WARNING! For safety reasons, DO NOT throw the battery in fire,
DO NOT short circuit the contacts, and DO NOT disassemble the
battery. If there is any abnormal operation or damage to the
battery pack caused by impact, turn OFF the Notebook PC and
contact an authorized service center.
Battery Care
The Notebook PC’s battery pack, like all rechargeable batteries, has
a limit on the number times it can be recharged. The battery packs
useful life will depend on your environment temperature, humidity,
and how your Notebook PC is used. It is ideal that the battery be
used in a temperature range between 10˚C and 35˚C (50˚F and
95˚F). You must also take into account that the Notebook PC’s
internal temperature is higher than the outside temperature. Any
temperatures above or below this range will shorten the life of the
battery. But in any case, the battery packs usage time will eventually
decrease and a new battery pack must be purchased from an
authorized dealer for this Notebook PC. Because batteries also have
a shelf life, it is not recommended to buy extras for storing.
Downloaded from LpManual.com Manuals

Table of Contents

Other manuals for Asus K53E

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus K53E and is the answer not in the manual?

Asus K53E Specifications

General IconGeneral
Bus typeDMI
Tjunction85 °C
Processor cache2 MB
Processor cores2
Processor modelB950
System bus rate5 GT/s
Processor familyIntel® Pentium®
Processor seriesIntel Pentium B900 Series for Mobile
Processor socketPGA988
Processor codenameSandy Bridge
Processor frequency2.1 GHz
Processor cache typeL3
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x8, 2x16, 1x8+2x4
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)21
Maximum number of PCI Express lanes16
Motherboard chipsetIntel® HM65 Express
HDD size2.5 \
HDD speed5400 RPM
HDD interfaceSATA II
Storage mediaHDD
Optical drive typeDVD Super Multi DL
Card reader integratedYes
Total storage capacity320 GB
Compatible memory cardsMemory Stick (MS), MMC, MS PRO, SD
Number of HDDs installed1
Display diagonal15.6 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Internal memory4 GB
Memory clock speed1333 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory8 GB
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1100 MHz
Audio system-
Speakers manufacturerAltec Lansing
Pointing deviceTouchpad
Front camera resolution (numeric)0.3 MP
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version3.0+HS
Cabling technology10/100/1000Base-T(X)
Top Wi-Fi standardWi-Fi 4 (802.11n)
Operating system installedWindows 7 Home Premium
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports0
Password protection typeBIOS, HDD
Battery capacity5200 mAh
Battery life (max)- h
Number of battery cells6
Processor ARK ID55627
Processor package size37.5x37.5 (rPGA988B) mm
Supported instruction setsSSE4.x
Weight and Dimensions IconWeight and Dimensions
Depth253 mm
Width378 mm
Weight2600 g
Height (rear)34.9 mm
Height (front)28.3 mm
