Asus K53SV User Manual

18 Notebook PC User Manual
Battery Lock - Spring
The spring battery lock is used to keep the battery
pack secured. When the battery pack is inserted, it will
automatically lock. To remove the battery pack, this spring
lock must be held in the unlocked position.
Battery Pack
The battery pack is automatically charged when the
Notebook PC is connected to an AC power source and
maintains power to the Notebook PC when AC power is
not connected. This allows use when moving temporarily
between locations. Battery time varies by usage and by
the specifications for this Notebook PC. The battery pack
cannot be disassembled and must be purchased as a single
unit.
Hard Disk Drive Compartment
The hard disk drive is secured in a compartment. Visit an
authorized service center or retailer for information on hard
disk drive upgrades for your Notebook PC. Only purchase
hard disk drives from authorized retailers of this Notebook
PC to ensure maximum compatibility and reliability.
Memory (RAM) Compartment
The memory compartment provides expansion capabilities
for additional memory. Additional memory will increase
application performance by decreasing hard disk access.
The BIOS automatically detects the amount of memory in
the system and configures CMOS accordingly during the
POST (Power-On-Self-Test) process. There is no hardware or
software (including BIOS) setup required after the memory
is installed. Visit an authorized service center or retailer for
information on memory upgrades for your Notebook PC.
Only purchase expansion modules from authorized retailers
of this Notebook PC to ensure maximum compatibility and
reliability.
1
2
3
4

Asus K53SV Specifications

General

Graphics	NVIDIA GeForce GT 540M
Display	15.6" 16:9 HD (1366x768) LED Backlight
Optical Drive	DVD Super Multi
Card Reader	3 -in-1 card reader ( SD/ MS/ MMC)
Networking	802.11 b/g/n
LAN	10/100/1000 Base T
Weight	2.6 kg (with 6 cell battery)
Processor	Intel Core i5 or i7
RAM	Up to 8GB DDR3
Storage	500GB or 750GB
Operating System	Windows 7 Home Premium
Camera	0.3MP
Interface	1 x USB 3.0, 2 x USB 2.0, 1 x VGA Port, 1 x HDMI, 1 x RJ45 LAN Jack for LAN insert, 1 x Microphone-in jack
Audio	Built-in Speakers And Microphone
Battery	6-cell Li-ion
Power Adapter	Output : 19 V DC, 4.74 A, 90 W Input : 100 -240 V AC, 50/60 Hz universal
Dimensions	37.8 x 25.3 x 3.49 cm (WxDxH)
