Asus K53SV User Manual

40 Notebook PC User Manual
Microsoft Windows Keys
There are two special Windows keys on the keyboard as described
below.
The key with the Windows Logo activates the Start menu
located at the bottom left of the Windows desktop.
The other key, that looks like a Windows menu with
a small pointer, activates the properties menu and is
equivalent to pressing the right mouse button on a
Windows object.
Fn+Enter (extended keyboard): Toggles Windows
“Calculator” application.
Extended Keyboard
The extended keyboard
has a dedicated numeric
keypad for easy number
entry. Use [Num Lk / Scr
Lk] to toggle between
using the extended
keypad as numbers or
as pointer directions. The
pointer direction keys are
for navigation between fields
or cells such as those in a
spreadsheet or table.

Asus K53SV Specifications

General

Graphics	NVIDIA GeForce GT 540M
Display	15.6" 16:9 HD (1366x768) LED Backlight
Optical Drive	DVD Super Multi
Card Reader	3 -in-1 card reader ( SD/ MS/ MMC)
Networking	802.11 b/g/n
LAN	10/100/1000 Base T
Weight	2.6 kg (with 6 cell battery)
Processor	Intel Core i5 or i7
RAM	Up to 8GB DDR3
Storage	500GB or 750GB
Operating System	Windows 7 Home Premium
Camera	0.3MP
Interface	1 x USB 3.0, 2 x USB 2.0, 1 x VGA Port, 1 x HDMI, 1 x RJ45 LAN Jack for LAN insert, 1 x Microphone-in jack
Audio	Built-in Speakers And Microphone
Battery	6-cell Li-ion
Power Adapter	Output : 19 V DC, 4.74 A, 90 W Input : 100 -240 V AC, 50/60 Hz universal
Dimensions	37.8 x 25.3 x 3.49 cm (WxDxH)
