Asus K53SV User Manual

22 Notebook PC User Manual
HDMI
HDMI Port
HDMI (High-Definition Multimedia Interface) is an
uncompressed all-digital audio/video interface between
any audio/video source, such as a set-top box, DVD player,
and A/V receiver and an audio and/or video monitor, such
as a digital television (DTV). Supports standard, enhanced,
or high-definition video, plus multi-channel digital audio
on a single cable. It transmits all ATSC HDTV standards and
supports 8-channel digital audio, with bandwidth to spare
to accommodate future enhancements or requirements.
USB Port (3.0) (on selected models)
The USB (Universal Serial Bus) port is compatible with USB
3.0, 2.0, or USB 1.1 devices such as keyboards, pointing
devices, cameras, hard disk drives, printers, and scanners
connected in a series up to 4.8Gbits/sec (USB 3.0),
480Mbits/sec (USB 2.0), and 12Mbits/sec (USB 1.1). USB
allows many devices to run simultaneously on a single
computer, with some peripherals acting as additional
plug-in sites or hubs. USB supports hot-swapping of devices
so that most peripherals can be connected or disconnected
without restarting the computer.
5
6

Asus K53SV Specifications

General

Graphics	NVIDIA GeForce GT 540M
Display	15.6" 16:9 HD (1366x768) LED Backlight
Optical Drive	DVD Super Multi
Card Reader	3 -in-1 card reader ( SD/ MS/ MMC)
Networking	802.11 b/g/n
LAN	10/100/1000 Base T
Weight	2.6 kg (with 6 cell battery)
Processor	Intel Core i5 or i7
RAM	Up to 8GB DDR3
Storage	500GB or 750GB
Operating System	Windows 7 Home Premium
Camera	0.3MP
Interface	1 x USB 3.0, 2 x USB 2.0, 1 x VGA Port, 1 x HDMI, 1 x RJ45 LAN Jack for LAN insert, 1 x Microphone-in jack
Audio	Built-in Speakers And Microphone
Battery	6-cell Li-ion
Power Adapter	Output : 19 V DC, 4.74 A, 90 W Input : 100 -240 V AC, 50/60 Hz universal
Dimensions	37.8 x 25.3 x 3.49 cm (WxDxH)
