Asus M2N-MX User Manual

ASUS M2N-MX 1-7
1.5.1 Motherboard layout
1.5 Motherboard overview
22.4cm (8.8in)
DDR2 DIMM_A1 (128 bit,240-pin module) DDR2 DIMM_B1 (128 bit,240-pin module) DDR2 DIMM_A2 (128 bit,240-pin module) DDR2 DIMM_B2 (128 bit,240-pin module)
EATXPWR
PRI_IDE
FLOPPY
Socket M2
PWR_FAN
SATA3
SATA1
SATA4
SATA2
NVIDIA MCP61G
M2N-MX
24.5cm (9.6in
)
PANEL
USB78
USB910
USB56
PCI2
PCI1
PCIEX1_1
PCIEX16
CR2032 3V
Lithium Cell
CMOS Power
R
SB_PWR
SPDIF_O
AAFP
CPU_FAN
4Mb BIOS
Super I/O
AD1986A
ATTANSIC
F001
CD
PS2_USB_PWR
ATX12V
PS/2KBMS
T: Mouse
B: Keyboard
PARALLEL
POR
T
AUDIO
LAN_USB34
USB12
VGA COM1
CLRTC

Asus M2N-MX Specifications

General

ECC	Yes
Number of memory slots	4
Maximum internal memory	4 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
Maximum number of SMP processors	1
USB 2.0 connectors	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	ADI AD1986A
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Bundled software	ASUS PC Probe II ASUS LiveUpdate AMD Cool'n'Quiet
Graphics card	GeForce 6100
Special features	ASUS Q-Fan ASUS My Logo 2 ASUS CrashFreeBIOS2 ASUS EZ Flash 2
Manageability features	WfM 2.0, DMI 2.0, WOL PME, WOR, PXE
Controller interface type	NVIDIA MCP61P
Networking features	Gigabit Ethernet
BIOS memory size	32 Mbit
RAID levels	0, 1, 0+1

Weight and Dimensions

Depth	222 mm
Width	245 mm
