Configure DRAM Timing by SPD [Enabled]
When this item is enabled, the DRAM timing parameters are set according
to the DRAM SPD (Serial Presence Detect). When disabled, you can
manually set the DRAM timing parameters through the DRAM sub-items.
The following sub-items appear when this item is Disabled. Conguration
options: [Enabled] [Disabled]
DRAM CAS# Latency [5]
Controls the latency between the SDRAM read command and the time
the data actually becomes available. Conguration options: [3] [4] [5]
[6]
DRAM RAS# to CAS# Delay [6 DRAM Clocks]
Controls the latency between the DDR SDRAM active command and
the read/write command. Conguration options: [2 DRAM Clocks] [3
DRAM Clocks] [4 DRAM Clocks] [5 DRAM Clocks] [6 DRAM Clocks]
DRAM RAS# Precharge [6 DRAM Clocks]
Controls the idle clocks after issuing a precharge command to the DDR
SDRAM. Conguration options: [2 DRAM Clocks] [3 DRAM Clocks] [4
DRAM Clocks] [5 DRAM Clocks] [6 DRAM Clocks]
DRAM RAS# Activate to Precha [15 DRAM Clocks]
Conguration options: [4 DRAM Clocks] [5 DRAM Clocks]...[18 DRAM
Clocks]
DRAM Write Recovery Time [4 Clocks]
Set the write recovery timing.
DRAM TRFC [30 DRAM Clocks]
Conguration options: [20 DRAM Clocks] [25 DRAM Clocks] [30 DRAM
Clocks] [35 DRAM Clocks] [42 DRAM Clocks]
DRAM TRRD [10]
Conguration options: [10]
Initiate Graphic Adapter [PEG/PCI]
Allows you to select the graphics controller as the primary boot device.
Conguration options: [PCI/PEG] [PEG/PCI]
Initiate Graphic Mode Select [Enabled, 8MB]
Allows you to select the amount of system memory used by the Internal
graphics device. Conguration options: [Disabled] [Enabled,1MB] [Enabled,
8MB]
PEG Force x1 [Disabled]
Conguration options: [Enabled] [Disabled]

Asus M2N-MX Specifications

General

ECC	Yes
Number of memory slots	4
Maximum internal memory	4 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
Maximum number of SMP processors	1
USB 2.0 connectors	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	ADI AD1986A
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Bundled software	ASUS PC Probe II ASUS LiveUpdate AMD Cool'n'Quiet
Graphics card	GeForce 6100
Special features	ASUS Q-Fan ASUS My Logo 2 ASUS CrashFreeBIOS2 ASUS EZ Flash 2
Manageability features	WfM 2.0, DMI 2.0, WOL PME, WOR, PXE
Controller interface type	NVIDIA MCP61P
Networking features	Gigabit Ethernet
BIOS memory size	32 Mbit
RAID levels	0, 1, 0+1

Weight and Dimensions

Depth	222 mm
Width	245 mm
