ASUS M4A77T 2-11
DRAM Command Rate [Auto]
Conguration options: [Auto] [1T] [2T]
TCL [Auto]
Conguration options: [Auto] [4 CLK] ~ [12 CLK]
TRCD [Auto]
Conguration options: [Auto] [5 CLK] ~ [12 CLK]
TRP [Auto]
Conguration options: [Auto] [5 CLK] ~ [12 CLK]
TRAS [Auto]
Conguration options: [Auto] [15 CLK] ~ [30 CLK]
TRTP [Auto]
Conguration options: [Auto] [4 CLK] ~ [7 CLK]
TRC [Auto]
Conguration options: [Auto] [11 CLK] ~ [41 CLK]
TWR [Auto]
Conguration options: [Auto] [5 CLK] [6 CLK] [7 CLK] [8 CLK] [10 CLK] [12 CLK]
TRRD [Auto]
Conguration options: [Auto] [4 CLK] ~ [7 CLK]
TRWTTO [Auto]
Conguration options: [Auto] [3 CLK] ~ [17 CLK]
TWRRD [Auto]
Conguration options: [Auto] [2 CLK] ~ [10 CLK]
The conguration options for some of the following items vary depending on the DIMMs you
install on the motherboard.
HT Over Voltage [Auto]
Sets the HT over voltage. The values range from 1.20000V to 1.38000V with a 0.01000V
increment. Use the <+> / <-> keys to adjust the value. Conguration options: [Auto] [Max. =
1.38000V] [Min. = 1.20000V]
DRAM Frequency [Auto]
Selects the DRAM frequency programming method. If this item is set to [Auto], the DRAM
speed depends on the SPDs. Conguration options: [Auto] [800MHz] [1067MHz] [1333MHz]
[1600MHz]
Memory Over Voltage [Auto]
Sets the memory over voltage. The values range from 1.2000V to 2.4450V with a
0.0750V(1.2V~1.5V) or 0.0150V(1.5V~2.445V) increment. Use the <+> / <-> keys to adjust
the value. Conguration options: [Auto] [Max. = 2.4450V] [Min. = 1.2000V]
DRAM Timing/Driving Conguration

Asus M4A77T Specifications

General

ECC	Yes
Number of memory slots	4
Maximum internal memory	16 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
Maximum number of SMP processors	1
Number of SATA connectors	6
Headphone outputs	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Motherboard chipset	AMD 770
Motherboard form factor	ATX
PCI Express x1 slots	2
Controller 2nd interface type	IDE/SATA
LAN controller	Realtek RTL8112L
ACPI version	2.0
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	213 mm
Width	305 mm
