Asus Maximus V Formula User Manual

xi
MAXIMUS V FORMULA Series specications summary
(continued on the next page)
Storage
Intel
®
Z77 Express Chipset with RAID 0, 1, 5, 10 support
- 2 x SATA 6.0 Gb/s ports (red)
- 2 x SATA 3.0 Gb/s ports (black)
- 1 x eSATA 3.0 Gb/s ports
- 1 x mSATA 3.0 Gb/s slot on mPCIe Combo™ expansion card
- Supports Intel
®
Smart Response Technology, Intel
®
Rapid Start
Technology and Intel
®
Smart Connect Technology*
ASMedia
®
SATA 6Gb/s controller*
- 4 x SATA 6.0 Gb/s ports [red]**
* Supports Intel
®
Core™ processors on Windows
®
7 operating system.
** These SATA ports are for data hard drives only. ATAPI devices are not
supported.
LAN 1 x Intel
®
Gigabit LAN Controller
Wireless Data Network Wi-Fi 802.11 a/b/g/n supports dual frequency band 2.4/5 GHz on
mPCIe Combo™ expansion card
Bluetooth Bluetooth v4.0/3.0+HS
* The module is pre-installed on the mPCIe Combo™
ROG SupremeFX HD
Audio
SupremeFX IV, built-in 7.1 Channel High Denition
Audo CODEC
High delity headphone amplier
Texas Instruments (120dB SNR, -117dB THD+N at VCC+-12V,
RL=600 Ω, f=1KHz)
SupremeFX Shielding™ Technology
ELNA Premium Audio Capacitors
1500 uF Audio Power Capacitor
Output Signal-to-Noise Ratio (A-Weighted): 110dB
Output THD+N at 1KHz: 95dB
Supports jack-detection, multi-streaming, front panel jack-retasking
Blu-ray audio layer content protection
Optical S/PDIF input and output ports at back panel
Audio Features:
DTS Ultra PC II
DTS Connect
USB
Intel
®
Z77 Express Chipset
- 4 x USB 3.0 ports (2 ports at mid-board [red]*, 2 ports at back
panel [blue])
- 8 x USB 2.0 ports (4 ports at mid-board, 1 port reserved for
ROG Connect [white], 3 ports at back panel)
ASMedia
®
USB 3.0 controller
- 2 x USB 3.0 ports at back panel (blue)
* UASP standard on the Intel
®
native USB 3.0 only supports Windows
®
8.

Asus Maximus V Formula Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133, 2200, 2400, 2600, 2666, 2800 MHz
Supported memory module capacities	1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	2
Number of SATA connectors	10
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
I/O ports	2x RCA 1x USB 2.0 2x 3.5mm 1x 2.5mm
Manageability features	WfM2.0, DMI2.0, WOL by PME, PXE
HDMI version	1.4a
Headphone outputs	5
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel Z77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	Extended ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA, SATA II, SATA III
Graphics card	HD Graphics
OpenGL version	4.2
DirectX version	11
Maximum resolution	2560 x 1600 pixels
Parallel processing technology support	2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX, LucidLogix Virtu
PCI Express x16 slots	3
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x16, 2x8
Cables included	SATA
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Networking features	Gigabit LAN
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	257 mm
Width	305 mm
