ASUS P5B 4-23
Front Panel Support Type [AC97]
Allows you to set the front panel audio connector (AAFP) mode to legacy
AC’97 or high‑denition audio depending on the audio standard that the front
panel audio module supports. Conguration options: [AC97][HD Audio]
OnboardPCIEGbLAN[Enabled]
Allows you to enable or disable the onboard PCIE Gigabit LAN controller.
Conguration options: [Disabled] [Enabled]
LAN Option ROM [Disabled]
Allows you to enable or disable the boot ROM in the onboard LAN controller.
This item appears only when the Onboard LAN item is set to Enabled.
Conguration options: [Disabled] [Enabled]
JMicronSATA/PATAController[Enabled]
Allows you to enable or disable the JMicron SATA/PATA controller.
Conguration options: [Disabled] [Enabled]
JMicron SATA Controller Mode [AHCI]
Allows you to set the JMicron SATA controller mode.This item appears only
when the JMicron SATA/PATA Controller item is set to Enabled.
Conguration options: [IDE] [AHCI] [RAID]
The JMicron PATA controller keeps IDE mode.
SerialPort1Address[3F8/IRQ4]
Allows you to select the Serial Port1 base address. Conguration options:
[Disabled] [3F8/IRQ4][2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
ParallelPortAddress[378]
Allows you to select the Parallel Port base addresses.
Conguration options: [Disabled] [378] [278] [3BC]
ParallelPortMode[ECP]
Allows you to select the Parallel Port mode.
Conguration options: [Normal] [Bi‑directional] [EPP] [ECP]
ECP Mode DMA Channel [DMA3]
Appears only when the Parallel Port Mode is set to [ECP]. This item
allows you to set the Parallel Port ECP DMA.
Conguration options: [DMA0] [DMA1] [DMA3]
Parallel Port IRQ [IRQ7]
Conguration options: [IRQ5] [IRQ7]

Asus P5B Specifications

General

ECC	No
Number of memory slots	4
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Maximum number of SMP processors	1
USB 2.0 connectors	3
S/PDIF out connector	Yes
Number of SATA connectors	5
Special features	- ASUS AI Gear - ASUS AI Nap - ASUS Q-Fan 2 - ASUS Noise Filter - ASUS Q-Connector - ASUS O.C. Profile - ASUS CrashFree BIOS 3 - ASUS EZ Flash 2
Manageability features	WfM 2.0, DMI 2.0, WOL @ PME, WOR @ PME, PXE
Controller interface type	JMicron JMB363
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio output channels	7.1 channels
Motherboard form factor	ATX
Bundled software	ASUS PC Probe II ASUS Update AI Booster
Networking features	Gigabit Ethernet
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	245 mm
Width	305 mm
