5-245-24

5-24

Chapter 5: Software supportChapter 5: Software support

Chapter 5: Software support

RAID Mode................................ Stripe

Un-used Drive(s)......................... 4

Drive(s) in Array........................ 0

Array Capacity (size in MB).............. 8056

[ Auto Configuration Menu ]

[ Array Configuration ]

Setup Array Type as: RAID 0

[→,←,Space] Change Option [CTRL-Y] Save [ESC] Exit

3. At the bottom of the screen are the navigation keys. These keys allow

you to move through and select from the menu options.

Auto-configuring a RAID arrayAuto-configuring a RAID array

Auto-configuring a RAID array

This option allows you to select a supported RAID set for the utility to

automatically configure.

To auto-configure a RAID set:

1. From the IT8212 Setup Utility screen, press <1>. The following screen

appears.

2. Use the left or right arrow keys or the space bar to select a RAID set.

As you select an option, the screen displays the array configuration of

the RAID based on the number of IDE devices installed.

3. Press <Ctrl+Y> to save your RAID set.

4. Press <Esc> to exit.

4. Press the number of your selection or <Esc> to exit.

[1]..[5] Select [ESC] Exit
