Asus P5Q-E User Manual

xiii
(continued on the next page)
P5Q-E specications summary
Audio ADI
®
AD2000B 8-channel High Denition Audio CODEC
- Supports Jack-Detecting, Multi-streaming, and Front
Panel Jack-Retasking
- Coaxial / Optical S/PDIF out ports at back I/O
- ASUS AI Audio 2
- ASUS Noise-Filtering
USB 12 x USB 2.0 ports (6 ports at mid-board, 6 ports at back
panel)
ASUS Unique Features ASUS Exclusive Features:
- ASUS 8-Phase Power Design
- ASUS Express Gate
ASUS Power Saving Solution:
- ASUS EPU-6 Engine
- ASUS AI Nap
ASUS Quiet Thermal Solution:
- ASUS Fanless Design: Heat-pipe solution
- ASUS Fanless Design: Stack Cool 2
- ASUS Fan Xpert
ASUS EZ DIY:
- ASUS Drive Xpert
- ASUS DieHard BIOS
- ASUS Q-Shield
- ASUS Q-Connector
- ASUS O.C. Prole
- ASUS EZ Flash 2
- ASUS AI Direct Llink
- ASUS Onboard Switch
ASUS Stylish Features ASUS MyLogo3™
ASUS Exclusive
Overclocking Features
ASUS AI Booster utility
Precision Tweaker 2:
- vCore: Adjustable CPU voltage at 0.00625V
increment
- vDIMM: 64-step DRAM voltage control
- vChipset (N.B.): 55-step chipset voltage control
- vCPU PLL: 64-step CPU PLL voltage control
- vFSB Termination: 40-step voltage control
SFS (Stepless Frequency Selection)
- FSB tuning from 200MHz up to 800MHz at 1MHz
increment
- PCI Express frequency tuning from 100MHz up to
180MHz at 1MHz increment
Overclocking Protection:
- ASUS C.P.R.(CPU Parameter Recall)

Asus P5Q-E Specifications

General

Non-ECC	Yes
Number of memory slots	4
Maximum internal memory	16 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Number of COM connectors	1
Number of SATA connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
Audio chip	ADI AD2000B
Audio output channels	7.1 channels
Motherboard form factor	ATX
BIOS memory size	16 Mbit
RAID levels	0, 1, 10

Weight and Dimensions

Depth	244 mm
Width	305 mm
