Asus P8H61-I R2.0 User Manual

viii
P8H61-I R2.0 specications summary
(continued on the next page)
CPU LGA1155 socket for Intel
®
3
nd
/ 2
nd
Generation Core™ i7 / Core™ i5 /
Core™ i3 / Pentium
®
/ Celeron
®
processors
Supports 22/32nm CPU
Supports Intel
®
Turbo Boost technology 2.0
* The Intel
®
Turbo Boost technology 2.0 support depends on the
CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H61 Express Chipset
Memory 2 x DIMMs, maximum 16GB, DDR3 2200 (O.C.) / 2100 (O.C.) /
2000 (O.C.) / 1800 (O.C.) / 1600 (O.C.) / 1333 / 1066 MHz, non-
ECC, un-buffered memory*
Dual-channel memory architecture
*When you install a total memory of 4GB capacity or more,
Windows
®
32-bit operating system may only recognize less than
3GB. We recommend a maximum of 3GB system memory if you
are using a Windows
®
32-bit operating system.
**DDR3 1600 MHz and higher memory frequency is supported by
Intel
®
3rd generation processors.
***Refer to www.asus.com for the latest Memory QVL (Qualied
Vendors List).
Expansion slots 1 x PCI Express 3.0*/2.0 x16 slot
*PCIe 3.0 speed is supported by Intel
®
3rd generation processors.
Graphics Supports HDMI with max. resolution up to 1920 x 1200 @60Hz
Supports DVI with max. resolution up to 1920 x 1200 @60Hz
Supports D-Sub with max. resolution up to 2048 x 1530 @75Hz
Max. UMA memory: 1748MB
Storage Intel
®
H61 Express Chipset:
- 4 x Serial ATA 3.0 Gb/s connectors (blue)
- Supports AHCI Mode (in Windows
®
7/Vista)
LAN Realtek
®
RTL8111F Gigabit LAN controller
Audio VIA VT1708S 8-channel High Denition Audio CODEC
- Supports Jack-Detection, Multi-streaming, and Front Panel Jack-
Retasking
USB 2 x USB 3.0/2.0 ports (the back panel)
8 x USB 2.0/1.1 ports (4 ports at the mid-board, 4 ports at the back
panel)

Asus P8H61-I R2.0 Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 2000, 2200 MHz
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Headphone outputs	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1708S
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Supported storage drive interfaces	SATA, SATA II
Graphics card	HD Graphics
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1748 MB
Parallel processing technology support	Not supported
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x16
Special features	2 x Thunderbolt
Cables included	SATA
LAN controller	Realtek RTL8111F
Networking features	Gigabit LAN
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	171 mm
