2-16 ASUS P8H61-M LX
Be cautious when changing the settings of the Advanced menu items. Incorrect eld values
can cause the system to malfunction.
2.5 Advanced menu
The Advanced menu items allow you to change the settings for the CPU and other system
devices.
Main
Ai Tweaker
Advanced Monitor Boot Tool
Exit
CPU Conguration Parameters
EFI BIOS Utility - Advanced Mode
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
> CPU Conguration
> System Agent Conguration
> PCH Conguration
> SATA Conguration
> USB Conguration
> Onboard Devices Conguration
> APM
2.5.1 CPU Conguration
The items in this menu show the CPU-related information that the BIOS automatically
detects.
The items shown in submenu may be different due to the CPU you installed.
2.4.12 PCH Voltage [Auto]
Allows you to set the Platform Controller Hub voltage. The values range from 0.735V to
1.685V with a 0.005V interval.
• The values of the iGPU Voltage, DRAM Voltage, VCCIO Voltage, CPU PLL Voltage,
and PCH Voltage items are labeled in different color, indicating the risk levels of high
voltage settings.
• The system may need better cooling system to work stably under high voltage settings.
