P8Z77-V LE PLUS specications summary
(continued on the next page)
CPU LGA1155 socket for Intel
®
3
rd
/ 2
nd
Generation Core™ i7 / Core™ i5 /
Core™ i3 / Pentium
®
/ Celeron
®
processors
Supports 22nm / 32nm CPU
Supports Intel
®
Turbo Boost technology 2.0*
* The Intel
®
Turbo Boost technology 2.0 support depends on the CPU
types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
Z77 Express Chipset
Memory 4 x DIMMs, max. 32GB, DDR3 2400(O.C.) / 2200(O.C.) / 2133(O.C.) /
1866 (O.C.) / 1600 / 1333 / 1066 MHz, non-ECC, un-buffered memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of
individual CPUs. Please refer to the memory QVL for details.
Graphics Integrated Graphics Processor - Intel
®
HD Graphics support
Multi-VGA output support: DisplayPort, HDMI, DVI, RGB ports
- Supports DisplayPort 1.1a with max. resolution of 2560 x 1600 @60Hz
- Supports HDMI with max. resolution of 1920 x 1200 @60Hz
- Supports DVI with max. resolution of 1920 x 1200 @60Hz
- Supports RGB with max. resolution of 2048 x 1536 @75Hz
- Supports Intel
®
InTru
TM
3D / Insider
TM
/ Quick Sync Video / Clear Video
HD Technology / HD Graphics
- Maximum shared memory of 1696MB
Multi-GPU
support
Supports NVIDIA
®
Quad-GPU SLI™ Technology (with 2 PCIe x16
graphics card)
Supports AMD
®
Quad-GPU CrossFireX
TM
Technology*
Supports AMD
®
3-Way CrossFireX
TM
Technology*
Supports LucidLogix
®
Virtu MVP Technology**
* Disable PCIe x1_1 and PCIe x1_2 slots and manually set the PCIe
x16_3 to x4 mode in BIOS when conguring CrossFireX™ with dual
graphics cards.
** LucidLogix Virtu
®
MVP supports Windows
®
7 operating systems.
Expansion slots
2 x PCI Express 3.0* / 2.0 x16 slots (single at x16, or dual at x8 / x8
mode)
1 x PCI Express 2.0 x16 slot [black] (max. at x4 mode, compatible with
PCIe x1 and PCIe x4 devices)**
2 x PCI Express 2.0 x1 slots
2 x PCI slots
* PCIe 3.0 speed is supported by Intel
®
3
rd
generation Core
TM
processors.
** The PCIe x16_3 slot shares the bandwidth with the PCIe x1_1 and
PCIe x1_2 slots. The default setting is x2 mode. Go to the BIOS setup
to change the settings.

Asus P8Z77-V LE PLUS Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1333, 1600, 1800, 1866, 2000, 2133, 2200, 2400 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Number of Parallel ATA connectors	0
Headphone outputs	6
USB 2.0 ports quantity	2
Audio chip	Realtek ALC889
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel Z77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2560 x 1600 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX, Quad-GPU SLI
PCI Express slots version	3.0
PCI Express configurations	1x4, 1x16, 2x8
Controller 2nd interface type	Marvell PCIe SATA 6Gb/s, ASMedia USB 3.0
Cables included	SATA
LAN controller	Realtek RTL8111F
Networking features	Gigabit LAN
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	244 mm
Width	305 mm
