Asus ROG STRIX Z390-E GAMING User Manual

x
(continued on the next page)
LAN
Intel
®
I219-V Gigabit LAN- Dual interconnect between the integrated
Media Access Controller (MAC) and physical layer (PHY)
Anti-surge LANGuard
ROG GameFirst V technology
Wireless Data Network
Intel
®
Wireless-AC 9560
2 x 2 Wi-Fi with MU-MIMO 802.11 a/b/g/n/ac supports dual
frequency band 2.4/5 GHz
Supports channel bandwidth: HT20/HT40/HT80/HT160. Up to
1.73Gbps transfer speed
Bluetooth
Bluetooth v5.0
Audio
ROG SupremeFX S1220A 8-Channel High Definition Audio
CODEC
- Supports up to 32-Bit/192kHz playback*
- Impedance sense for front and rear headphone outputs
- High quality 120dB SNR stereo playback output and 113dB SNR
recording input
- SupremeFX Shielding Technology
- Dual OP Ampliers
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- Optical S/PDIF out port at back panel
Audio Features:
- Sonic Studio III + Sonic Studio Link
- Sonic Radar III
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-Channel audio.
USB
Intel
®
Z390 Chipset
- 1 x USB 3.1 Gen 2 front panel connector
- 4 x USB 3.1 Gen 2 ports
(3 Type-A [red] and 1 Type-C [black] at back panel)
- 4 x USB 3.1 Gen 1 ports
(2 ports at back panel [blue], 2 ports at mid-board)
- 6 x USB 2.0 ports
(2 ports at back panel [black], 4 ports at mid-board)
ROG STRIX Z390-E GAMING specifications summary

Asus ROG STRIX Z390-E GAMING Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666, 2800, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3733, 3866, 4000, 4133, 4266 MHz
Component for	PC
Motherboard chipset	Intel Z390
Audio output channels	7.1 channels
Motherboard form factor	ATX
Motherboard chipset family	Intel
Windows operating systems supported	Windows 10
BIOS type	UEFI AMI
ACPI version	6.1
BIOS memory size	16 Mbit
Cables included	SATA
USB 2.0 connectors	2
Number of SATA II connectors	0
Number of SATA III connectors	6
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
PCI Express x1 (Gen 3.x) slots	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Intel® I219-V
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	5.0
RAID levels	0, 1, 5, 10
Graphics card	HD Graphics
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	2-Way SLI, 3-Way CrossFireX
Processor socket	LGA 1151 (Socket H4)
Compatible processor series	Intel Celeron, Intel Pentium

Weight and Dimensions

Depth	244 mm
Width	305 mm
