Asus RT-AC59U User Manual

5
English
Preparing your modem
1. Unplug the power cable/DSL modem. If it has a
battery backup, remove the battery.
NOTE: If you are using DSL for Internet, you
will need your username/password from your
Internet Service Provider (ISP) to properly
conguretherouter.
2. Connect your modem to the router with the
bundled network cable.
3. Power on your cable/DSL modem.
4. Check your cable/DSL modem LED lights to ensure
the connection is active.
Unplug

Asus RT-AC59U Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	5
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, USB, WAN, WLAN
Antennas quantity	4
Antenna gain level (max)	5 dBi
Power source type	AC
Flash memory	16 MB
Internal memory	128 MB
Security algorithms	64-bit WEP, 128-bit WEP, SNMP, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPS
Windows operating systems supported	Windows 10, Windows 8, Windows 8.1
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	125 mm
Width	192 mm
Height	30 mm
Weight	348 g
