Asus RT-AC88U Quick Start Manual

13
English
Quick Internet Setup (QIS) with Auto-detection
TheQuickInternetSetup(QIS)functionguidesyouinquicklysettingupyour
Internetconnection.
NOTE:WhensettingtheInternetconnectionforthersttime,press
theResetbuttononyourwirelessroutertoresetittoitsfactorydefault
settings.
To use QIS with auto-detection:
1. LogintotheWebGUI.TheQISpagelaunchesautomatically.
NOTES:
• Bydefault,theloginusernameandpasswordforyourwireless
router'sWebGUIisadmin.
• Thewirelessrouter'sloginusernameandpasswordisdierentfrom
the2.4GHz/5GHznetworkname(SSID)andsecuritykey.Thewireless
router'sloginusernameandpasswordallowsyoutologintoyour
wirelessrouter'sWebGUItocongureyourwirelessrouter'ssettings.
The2.4GHz/5GHznetworkname(SSID)andsecuritykeyallowsWi-Fi
devicestologinandconnecttoyour2.4GHz/5GHznetwork.
Q10303_RT-AC88U_QSG.indb 13 2015/6/16 17:05:53

Asus RT-AC88U Specifications

General

Output current	2.37 A
Output voltage	19 V
AC input voltage	110 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
On/off switch	Yes
Product color	Black, Red
LED indicators	LAN, Power, USB, WAN, WLAN, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1750 Mbit/s
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
WLAN data transfer rates supported	1, 2, 5.5, 6, 9, 12, 18, 24, 36, 48, 54, 600, 1750 Mbit/s
Antennas quantity	4
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	8
Processor frequency	1400 MHz
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	74 mm
Width	118 mm
Height	33 mm
Weight	110 g
