Asus RT-AX88U User Manual

6
English
3. Set up your wireless environment.
3.0
Modem
Wall Power Outlet
LINE LAN RESET PWR
Power
Laptop
LAN
d
a
WAN
c
b
a. Insert your wireless router’s AC adapter to the DC-IN port and plug it to a
power outlet.
b. Using another network cable, connect your modem to your wireless router’s
WAN port.
c. Insert your modem’s AC adapter to the DC-IN port and plug it to a power
outlet.
d. Using the bundled network cable, connect your computer to your wireless
router’s LAN port. Ensure that the WAN and LAN LEDs are blinking.
4. Disable some settings on your computer.
a. Disable the proxy server, if enabled.
b. Set the TCP/IP settings to automatically obtain an IP address.
c. Disable the dial-up connection, if enabled.
NOTE: For more details on disabling your computer settings, refer to
Frequently Asked Questions (FAQs).

Asus RT-AX88U Specifications

General

Ethernet WAN	Yes
SIM card slot	-
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, Status, USB, WLAN, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 6 (802.11ax), 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	4804 Mbit/s
VPN support	IPSec Pass-Through, PPTP Pass-Through, L2TP Pass-Through, PPTP server, OpenVPN server, PPTP client, L2TP client, OpenVPN client
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN (RJ-45) ports	8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Antennas quantity	4
Security algorithms	WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPS
Processor frequency	1800 MHz
Output current	2.37 A
Output voltage	19 V
AC input voltage	110 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Package depth	250 mm
Package width	385 mm
Package height	126 mm
Package weight	2590 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	187.96 mm
Width	299.72 mm
Height	60.96 mm
Weight	1000 g
