Asus RT-N10P User Manual

7
Rear
Label Description
Reset
Press this button for more than five seconds to restore the
system to its factory default settings.
Power
Press this button to power on/off the wireless router.
Insert the AC adapter into this port to connect your router to
a power source.
LAN1-LAN4
Connect RJ-45 Ethernet cables to these ports to establish
LAN connection.
WAN
Connect an RJ-45 Ethernet cable to this port to establish
WAN connection.
WPS Press this button for more than four seconds to establish a
secure wireless connection with a WPS-supported wireless
device.
4 5 6321
1
2
3
4
5
6

Asus RT-N10P Specifications

General

VPN support	IPSec Pass-Throuth\\r PPTP Pass-Through\\r L2TP Pass-Through
Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	5
DHCP client	-
Antennas quantity	1
Antenna gain level (max)	5 dBi
Frequency band	2.4 GHz
Filtering description	IP, URL
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	124 mm
Width	168 mm
Height	30 mm
Weight	210 g
