2-2 Chapter2:Setup

2.2 Detaching the arm/stan(for VESA wall

mount)

ThedetachablestandoftheVB178(x)LSeriesLCDmonitorisspeciallydesigned

forVESAwallmount.

To detach the arm/stand:

1. Lowerthemonitortoitslowestheight,andtheninsetthemonitorheight

adjustmentlock.

2. Havethefrontofthemonitorfacedownonatable.

3. UseascrewdrivertoremovethefourscrewsontheVESAcover,theslideout

thearm/basetodetachitfromthemonitor.

• Werecommendthatyoucoverthetablesurfacewithsoftclothtoprevent

damagetothemonitor.

• Holdthestandofthemonitorwhenyouremovethescrews.

• TheVESAwallmountkit(100mmx100mm)ispurchasedseparately.

• ForuseonlywithULListedWallMountBracketwithminimumweight/load

14.8Kg(Screwsize:4mmx12mm)
