Asus VE248Q User Manual

2-3ASUS VE248Q/VE228Q Series LED Monitor
2.4 Connecting the cables
1. Connect the cables as the following instructions:
VE248Q
VE228Q
VGAHDMI
Earphone jack
Audio-in Display port
To connect the audio cable: • connect one end of the audio cable to the
monitor’s Audio-in port, the other end to the computer’s audio-out port.
To connect the power cord• : connect one end of the power cord securely to
the monitor’s AC input, the other end to a power outlet.
To connect the VGA/HDMI/Displayport cable• :
Plug one end of the VGA/HDMI/Displayport cable to the monitor’s VGA/a.
HDMI/Displayport port.
Connect the other end of the VGA/HDMI/Displayport cable to your b.
computer's VGA/HDMI/Displayport port.
Tighten the two screws to secure the VGA connector. c.
To use the earphone (only when an HDMI cable or DisplayPort cable are •
connected): connect the end with plug type to the monitor’s earphone jack.
When these cables are connected, you can choose the desired signal from the
Input Select item in the OSD menu.
2. Gather all the cables with the cable management slot.
cable management slot

Asus VE248Q Specifications

General

Color	black
Screen Type	led
Tiltable	yes
Wall Mount	100mm x 100mm
Touch Screen	no
Webcam	no
OS Compatibility	windows
Screen Size	24 inches
Panel Type	tn
Aspect Ratio	16:9
Resolution	1920 x 1080
Refresh Rate	76hz
Horizontal Viewing Angle	170 degrees
Vertical Viewing Angle	160 degrees
Response Time	2 milliseconds
Brightness	250 candela per square meter
Contrast Ratio	50, 000, 000:1
Built-In Speakers	yes
DVI	1
Headphones Output	yes
Power Saving Mode	0.5 watts
Power Consumption	40 watts
Width with Stand	24 inches
Net Weight without Stand	9.7 pounds
