Asus VG245 series User Manual

2-4 Chapter 2: Setup
2.3 Detaching the arm (for VESA wall
mount)
The detachable arm/base of this monitor is specially designed for VESA wall
mount.
To detach the arm/base:
1. Have the front of the monitor face down on a table.
2. Remove the rubbers in the four screw holes. (Figure 1)
3. Remove the base (Figure 2).
4. Use a screwdriver to remove the screw on the hinge (Figure 3), then remove
the hinge.
2
1
2
1
1
2
2
1
VG245HE
VG245H
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
• The VESA wall mount kit (100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load
22.7kg (Screw size: M4 x 10 mm)
(Figure 1)
(Figure 2) (Figure 3)

Asus VG245 series Specifications

General

Screen Size	24 inches
Resolution	1920 x 1080 (Full HD)
Refresh Rate	75 Hz
Response Time	1 ms (MPRT)
Panel Type	TN
Aspect Ratio	16:9
Brightness	250 cd/m²
Contrast Ratio	1000:1
Adaptive Sync	FreeSync
Viewing Angle	170° (H) / 160° (V)
Color Support	16.7 million colors
VESA Mount	100 x 100 mm
Swivel Adjustment	No
Height Adjustment	No
Flicker-Free	Yes
Low Blue Light	Yes
Ports	2 x HDMI, VGA
Tilt Adjustment	-5° to 33°
