2-3ASUS VG278 Series LCD Monitor
-5° ~ +33°
0°
90°
0°
90°
It is normal that the monitor slightly shakes while you adjust the viewing angle.
2.3 Detaching the arm (for VESA wall
mount)
The detachable arm/base of this monitor is specially designed for VESA wall
mount.
To detach the arm/base:

1. Have the front of the monitor face down on a table. (Figure 1)
2. Remove the base (Figure 2).
3. Use a screwdriver to remove the screw on the hinge (Figure 3), then remove
the hinge.
2
2
1
1
(Figure 1) (Figure 2) (Figure 3)
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.

Asus VG278 Series Specifications

General

Screen Size	27 inches
Refresh Rate	144Hz
Aspect Ratio	16:9
VESA Mount	100x100mm
Resolution	1920x1080
Panel Type	TN
Response Time	1ms
Ports	DisplayPort 1.2, HDMI 1.4, DVI-D
Features	GamePlus, GameVisual
Contrast Ratio	1000:1
Viewing Angle	170°/160°
Color Support	16.7M
