2-1

Chapter2:Setup

2.1 Detaching the arm/stand

(for VESA wall mount)

ThedetachablestandoftheVS228/VS238/VS247SeriesLCDmonitoris

speciallydesignedforVESAwallmount.

To detach the arm/stand:

1. Disconnectpowerandsignalcables.Carefullyputthefrontofthe

monitorfacedownonacleantable.

2. Useyourngersgentlypullawaytheplatethatcoversthestand

neck.Useascrewdrivertoremovethefourscrewsthatsecurethe

standtothemonitor.

3. Detachthestandfromthemonitor.

• Werecommendthatyoucoverthetablesurfacewithsoftclothto

preventdamagetothemonitor.

• Holdthestandofthemonitorwhileremovingthescrews.

• TheVESAwallmountkit(100x100mm)ispurchasedseparately.

• UseonlytheULListedWallMountBracketwithminimumweight/

loadaccordingtothemodellistedinthespecificationtable(Screw

size:M4x10mm).
