5ASUS VW246/VK246 LCD Monitor
2.3 Detaching the arm/base (for VESA wall mount)
The detachable arm/base of the VW246/VK246 LCD monitor is specially designed
for VESA wall mount.
To detach the arm/base:
1. Have the front of the monitor face down on a table.
2. Remove the rubbers in the four screw holes (Figure 1).
3. Use a screwdriver to remove the two arm screws, and then slide out the
arm/base to detach it from the monitor (Figure 2).
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
Arm/base
Rubbers in the
screw holes
Figure 1
Arm screws
Figure 2
