6.4 Nominal capacity
6.5 Correction factors and usage
6.6 Dimensions and weight
Refer to Fig. 3.
Dimension A is G or NPT.
Dimension F indicates the space needed for dismantling.
Type 9 17 32 44 60 120 150 175 280 390 520
l/s
9 17 32 44 60 120 150 175 280 390 520
cfm
19 36 68 93 127 254 318 371 551 826 1101
When the actual working pressure differs from the reference pressure, multiply the nominal capacity of the filter with the
corresponding correction factor to obtain the correct capacity.
Working pressure
1 bar 2 bar 3 bar 4 bar 5 bar 6 bar 7 bar 8 bar 10 bar 12 bar 14 bar 16 bar
Correction factor
0,38 0,53 0,65 0,75 0,83 0,92 1 1,06 1,20 1,31 1,41 1,50
Type A
(“)
B
(mm)
C
(mm)
D
(mm)
E
(mm)
F
(mm)
G
(mm)
H
(mm)
J
(mm)
K
(mm)
L
(mm)
M
(mm)
N
(mm)
P
(mm)
Q
(mm)
R
(mm)
Net
mass
9
3/8158136908303228217209280252606.61 kg
17
1/2158136908303228217209280252606.61.1 kg
32
1/2158136908358283217209280252606.61.3 kg
44
3/4 190 168 110 5 378 303 27.5 10 30 118 100 2 68 72 9 1.9 kg
44
1 190 168 110 5 378 303 27.5 10 30 118 100 2 68 72 9 1.9 kg
60
1 190 168 110 5 418 343 27.5 10 30 118 100 2 68 72 9 2.1 kg
120
1 1/2 240 218 140 5 549 449 34 10 42 157.5 131 2.5 92 103 9 4.2 kg
150
1 1/2 240 218 140 5 632 532 34 10 42 157.5 131 2.5 92 103 9 4.5 kg
175
1 1/2 240 218 140 5 632 532 34 10 42 157.5 131 2.5 92 103 9 4.6 kg
280
2 279 251 179 8 768 618 50 12 42 183 166 2.5 100 135 11 6.9 kg
280
2 1/2 279 251 179 8 768 618 50 12 42 183 166 2.5 100 135 11 6.9 kg
390
3 320 288 210 9 920 720 57 15 50 230.5 191 4 135 155 11 11 kg
520
3 320 288 210 9 1090 890 57 15 50 230.5 191 4 135 155 11 12.6 kg
A080-070401-010
Vendor Manual Atlas Copco A090-070423-004 PD & DD Filters Instruction Manual
Q-Pulse Id VM260
Active 09/09/2013
Page 9 of 90
