Instruction book
2.2
Installation proposal
(Fig.
2.3)
1.
FD dryer
2a.
DD-type general-purpose
prefilter
2c.
PD-type
afterfilter
3.
Air receiver
with condensate
drain
4.
Pressure
gauge
5.
Drain pipe
6.
Dryer
outlet
valve
7
.
By-pass
system
8
.
By-pass
valve
9.
Dryer
inlet
valve
Fig. 2.3
Installation proposal
1.
Insulating block
with heat exchangers
2.
Condenser
3.
Condensate
separator
4.
Condenser cooling fan
5.
Accumulator
Fig. 2.4
Side view
1
3
2
4
5
51533F
10
12
