4 Operating instructions
4.1 Initial start-up
Safety
The operator must apply all relevant Safety precautions.
General preparation
Air outlet valve
Condensate drain valve on air receiver
Step Action
1 Consult the installation instructions (see Installation).
2 Check that the electrical connections correspond to the local codes. The installation must
be earthed and protected against short circuits by fuses in all phases. An isolating switch
must be installed near the compressor.
3 Fit outlet valve (2), close it and connect the air net to the valve.
Connect condensate drain valve (4) of the air receiver to a drain collector. Close the valve.
Instruction book
40 2920 7105 31
