4.4 Pictographs
Pictographs
Pictographs
Reference Designation
1 Automatic condensate drain
2 Warning: before connecting compressor electrically, consult Instruction book for motor
rotation direction
3 Consult the specific instructions before greasing
4 Manual condensate drain
5 Torques for steel (Fe) or brass (CuZn) bolts
6 Switch off the voltage and depressurize the compressor before maintenance or repair
7 Warning: voltage
8 Warning: hot surface
9 Rotation direction of fan
Instruction book
80 2920 7140 52
