Atlas Copco XAHS 38 Kd User Manual

- 36 -
Technical specifications
COMPRESSOR / ENGINE SPECIFICATIONS
REFERENCE CONDITIONS
The inlet conditions are specified at the air inlet grating outside the canopy.
LIMITATIONS
Designation
XAHS 38 Kd XAS 58 Kd XAS 68 Kd XAS 48 G Kd XATS 68 Kd XAS 78 Kd XAS 88 Kd XAS 68 G Kd
Absolute inlet pressurebar 11111111
psi 14.5 14.5 14.5 14.5 14.5 14.5 14.5 14.5
Relative air humidity% 00000000
Air inlet temperature °C 20 20 20 20 20 20 20 20
°F 68 68 68 68 68 68 68 68
Nominal effective working
pressure
bar 1277710.3777
psi 175 100 100 100 150 100 100 100
Designation XAHS 38 Kd XAS 58 Kd XAS 68 Kd XAS 48 G Kd
Minimum effective receiver pressure bar 2222
psi 30303030
Maximum effective receiver pressure,
compressor unloaded
bar 13.5 8.8 8.8 8.8
psi 200 125 125 125
Maximum ambient temperature
at sea level
without aftercooler °C 50 50 50 50
°F 122 122 122 122
with aftercooler °C 45 45 45 45
°F 113113113113
Minimum starting temperature °C -10 -10 -10 -10
°F 14 14 14 14
Minimum starting temperature, with coldstart equipment °C -20 -20 -20 -20
°F -4 -4 -4 -4

Atlas Copco XAHS 38 Kd Specifications

General

Brand	Atlas Copco
Model	XAHS 38 Kd
Category	Air Compressor
Language	English
