5.7 Connecting MP-11x to Power
MP-11x is powered from a standard alternating current (AC) electrical outlet.
Table 5-1: Power Specifications
Physical Specification Description
Input Ratings
100-240 VAC, 50-60 Hz, 0.3A max
Max. Power Consumption Model Value
MP-112 16W
MP-114 with 2 x FXS / 2 x FXO 22W
MP-114 with 4 x FXO 4.9W
MP-114 with 4 x FXS 22W
MP-118 with 8 x FXS 24.5W
MP-118 with 8 x FXO 5.4W
MP-118 with 4 x FXS / 4 x FXO 24.5W
Warnings:
• The device must be connected only by professional service personnel.
• Ensure that the device connects to an electrical socket outlet that provides protective
earthing (grounding). Prior to connecting power, refer to the Regulatory Information
document supplied with the device.
• Use only the AC power cord supplied with the device.
