AVer PTC V2 Series Quick Start Guide

1
Product Introduction
Overview
(4) (5) (6) (7)(8)(9)
(10)
(11)
(12)
(2) (3)
(1)
(1) Camera lens
(5) PoE+ port
(9) micro-USB port
(2) IR sensor
(6) RS232 port
(10) HDMI port
(3) LED indicator
(7) RS422 port
(11) 3G-SDI port
(4) Kensington lock
(8) Audio in*
(12) DC Power jack
*Line input level: 1Vrms (max.).
*Mic input level: 50mVrms (max.); Supplied voltage:2.5V
RS232 and RS422 Connection
Connect through the RS232 or RS422 for camera control. For Visca over IP, please see the last
section.
◼ RS232
