AVMATRIX HVS0401E User Manual

3
3.SPECIFICATION
CONNECTION
Video In
IN1~IN3: HDMI type-A ×3; IN4: HDMI type-A/ Display Port ×1
Video Out
PGM: HDMI type-A×2
Multiview: HDMI type-A×1
USB Capture: USB type-C ×1
Streaming & PC control: LAN Port×1
Audio In
MIC/ Line ×2 (3.5mm audio)
RCA ×2 (stereo audio)
Tally Port
DB-15 ×1
Power In
DC 12V IN ×1
STREAM & RECORD
Encode Bitrate
2/ 4/ 8/ 12/ 16/ 24/ 32Mbps
Rate Control
CBR/ VBR
Stream Protocol
RTMP
Storage Format
SD card:FAT32/exFAT; USB disk: FAT32/exFAT/NTFS
REC Format
MP4/ TS
Encoder
H.265/ H.264 High/ H.264 Main/ H.264 Base
REC File Segment
1/ 5/ 10/ 20/ 30/ 60/ 90mins
FUNCTIONS
Functions
Image Still/ Transitioin Speed/ MUTE/ Audio follows Video/ Audio Mixer
Transitions
AUTO/ CUT
Effects
WIPE/ MIX/ FADE/ FTB
Layouts
PIP, Multiview
STANDARDS
HDMI In Format
Support
1080p 60/ 59.94/ 50/ 30/ 29.97/ 25/ 24/ 23.98/23.976
1080i 50/ 59.94/ 60
720p 60/ 59.94 /50/ 30/ 25/ 24
576i 50, 576p 50, 480p 59.94/ 60, 480i 59.94/ 60
PC HDMI/DP Input
Format Support
2560×1600, 2048×1152, 1920×1080,1680×1050, 1600×1200, 1600×900,
1400×1050, 1440×900, 1366×768, 1360×768,
1280×1024, 1280×960, 1280×800, 1280×768, 1280×720, 1280×600,
1152×864, 1024×768, 800×600, 640×480
HDMI PGM Out
1080p 60/ 50/ 30/ 25/ 24
1080i 60/ 50
HDMI Multiview Out
1080p60
